Our multi-purpose centrifuges offer a high-speed centrifugation platform which can be customized to fit workflow needs using a wide variety of rotors and accessories.
The intuitive design of the centrifuges and accessories enables easy access to parameter settings and quick rotation between applications. Features include automatic rotor recognition and backlit LCD.
The performance of these centrifuges is propelled by German engineering and high quality components for reliable use. Constructed from chemical-resistant stainless steel to ensure durability in lab use.
Product Specifications
Maximum Capacity(Rotor)
4 x 750 ml
Maximum Relative Centrifuge Force (x g)
26,331 g
Net Weight
118 kg (260 lb)
Program memories
99
Refrigeration Range
-20 °C (-4 °F );
40 °C ( 104 °F)
Speed Range
200 rpm ;
16,000 rpm
Rotor In Package
Not applicable
Acceleration Gear
10
Deceleration Gear
10
Dimensions (Length)
670 mm (26.4 in)
Dimensions (Width)
730 mm (28.7 in)
Dimensions (Height)
390 mm (15.4 in)
Lid lock
Motor driven
Safety Certification
CE;
FCC
Power Consumption
1,750 W
Display
2-line, backlit LCD
Noise Level
≤63±2 dB(A)
Power
AC Adapter (Included)
Pre-cool time
From room temperature to 4℃ ＜ 10min
Rotor Compatibility
Angle 4 x 85ml RB ID Hi;
Angle 12 x 15 ml RB/FA ID;
Angle 6 x 250 ml FB ID;
Angle 24 x 1.5 / 2.0 ml ID Sealable;
Angle 6 x 50 ml RB ID Hi;
Swing out 4 x 100 ml ID;
Angle 12 x 1.5 / 2.0 ml ID;
Angle 4 x 8-w PCR Strip ID;
Angle 44 x 1.5 / 2.0 ml ID;
Swing out 4x750ml ID Sealable;
Swing out 4 x 100 ml ID Sealable;
Angle 6 x 85 ml RB ID;
Angle 24 x 1.5 / 2.0 ml ID;
Rotor Angle 4x500ml ID;
Angle 6 x 85 ml RB ID Hi;
Angle 30 x 15 ml RB/FA ID;
Angle 30 x 1.5 / 2.0 ml ID Sealable;
Angle 10 x 50 ml FA ID;
Angle 64 x 0.5 ml ID;
Angle 20 x 10 ml RB ID Hi;
Angle 6 x 50 ml RB/FA ID;
Swing out 2 x 3MTP ID
Rotor Recognition Method
Auto
Running Time
Continous;
Quickspin;
10 sec to 99 h 59 min 59 sec
