Specifications
| Model | SR300 |
| Electric stirring motor | 220V, 50/60Hz, 1-phase, 200 watts, 1/4 HP Rotation: 450 rpm max. (+/-8%) Starting torque: 3.0 N.m Rated torque: 1.54 N.m Built-in gearbox ratio: 3:1 to 180:1 Controller: Delta, UL listed |
| Pneumatic stirring motor | Power: 1/4 HP Rotation: 450 rpm max. (+/-8%) Compressed air pressure range: 30 to 80 psi (0.2 to 0.55 MPa) Working temperature: -10C to +70C For constant use, set rpm to 80% of maximum rpm Motor lubricant: Mobil Grease XHP 222, Lithium Complex, Blue, NLGI Grade 2 Check, replenish, or replace every 500 hours Air lubricant type: JIS K2213-1 (ISOVG32) Recommended products: Shell Vitrea Oil 32, JOMO Turbine 32, COSMO Turbine 32 Air lubricant speed: 2-3 drops per minute Detach compressed air supply when not in use, left unattended, or at night |
| Port configuration | Lid: 12 inch triclamp Center motor port: 3 inch triclamp Drain port: 6 inch triclamp Drain port on/off valve: 2 inch triclamp Vacuum port: 1.5 inch triclamp Condenser recirculating fluid port: 1/2 inch female NPT Vessel jacket recirculating fluid port: 1 inch female NPT 50L/100L collection tank lid: 6 inch triclamp x 1, 1.5 inch triclamp x 4 |
| Main vessel | Volume: 300L Material: 316L grade stainless steel Interior finish: electropolished |
| Agitator | Structure: propeller, 3-blade, dual-layer Material: 316L grade stainless steel |
| Center fluid jacket | Volume: 50L Pressure rating: 20 psi Material: 304 grade stainless steel |
| Outer insulation jacket | Sealed Material: 304 grade stainless steel |
| Collection tank | Option 1: 20L x 2, 316L stainless steel, with manifold Option 2: 50L x 1, 304 stainless steel, with dolly (15.5 inch diameter, 23.5 inch height, 30 inch with dolly) Option 3: 100L x 1, 304 stainless steel, with dolly (15.5 inch diameter, 43 inch height, 49.5 inch with dolly) |
| Material | All wetted parts are 316L grade stainless steel on the main reactor body The rest of the reactor is 304 grade stainless steel, including motor coupling, triclamps, temp/pressure gauge adapters, and chassis |
| Main condenser | Style: shell and tube heat exchanger Number of tubes: 110 Condensing area: one sq meter |
| Pressure | Ultimate vacuum level: 1 Torr |
| Minimum fill volume | 60L |
| Temperature range | -55C to +250C (-67F to +482F) |
| Temperature sensor/display | Regular: BOOST.TTA.0101, -200C to 480C, 50.5 clamp Explosion proof: BOOST.TTA.0102, -200C to 480C, 50.5 clamp |
| Sealing gasket | Food grade Viton |
| Main mounting frame | Heavy duty 2.5 x 2.5 inch 304 grade stainless steel, mounted on four casters |
| Drain port ground clearance | Drain port: 19.5 inches Drain valve: 14 inches |
| Shipping weight (unit) | 770 Lbs / 990 Lbs |
| Shipping dimensions | 48 x 38 x 88 inch (WxDxH) |
| Assembled dimensions | 38 x 47 x 81 inch (WxDxH) without 20L receiving flasks assembled 51 x 47 x 81 inch (WxDxH) with 20L receiving flasks assembled |
| Compliance | ETL tested to UL and CSA standards C1D1 peer review by PSI (optional) |
- Weight 447.5 Kg
- Dimensions 50 Inch x 89 Inch x 40 Inch
