| Model | H200-7 |
| Temperature range | Ambient to 200°C |
| Electrical requirements | 220V 60Hz 1-Phase 2,900 watts |
| Heating capacity | 2,800 watts |
| Recirculating pump | Pumping speed: 21 liters per minute, adjustable Maximum head: 16 feet or 5 meters Power: 100 watts |
| Reservoir | Material: Type 304 stainless steel Capacity: 7 liters or 1.8 gallons Thermo fluid connection: M16 x 2 Fluid drain port: 3/8" hose barb with on/off valve |
| Temperature controller | Type: Digital microprocessor PID controlled Display: 7" touch screen Display unit: Celsius °C Temperature step: 0.1°C Temperature accuracy: +/- 2°C Temperature range: Ambient to 200°C |
| Working environment | -15°C/5°F to 25°C/77°F, at <66% humidity |
| Unit/shipping dimensions | 11.5 x 19 x 19" / 16 x 24 x 22" (WxDxH) |
| Unit/shipping weight | 35 Lbs / 50 Lbs |
| Safety | Short circuit and ground protection Over-current protection Over-temperature protection Upper/lower temperature alarm protection |
| Warranty | One year |
| Compliance | UL 61010-1 :2012 Ed.3+R:29Apr2016 CSA C22.2#61010-1 :2012 Ed.3 |
