| Model | G20h |
| Electrical requirements | 110V (±10%) 60Hz 1-Phase 1000 watts |
| Power consumption | 8.5 kW/day, Energy Star certified |
| Performance | Temperature range: -40°C to -86°C Time from ambient to -86°C: 5.5 hours Uniformity: ±4°C Time from -86°C to -50°C with door close at 25°C ambient: 4.5 hours 1 minute door open recovery time at 25°C ambient and -75°C running temp: 40 mins |
| Controller | Style: microcomputer controlled with analog display Range: -40°C to -86°C Step: 1°C Thermo sensor: PT100 Displays: internal temperature, ambient temperature, input voltage, error code Indicators: high/low temperature/battery alarms, sensor failure, power failure, condenser failure, door open, high ambient temperature, working condition |
| Compressor | Make: SECOP (formerly Danfoss), Germany Style: direct cooling Power: 115V 60Hz 1-PHASE, 0.54HP x 2 Number of compressors: two HC refrigerants: R290 (stage 1), R170 (stage 2) |
| Chamber | Dimensions: 24.4 x 28.2 x 51.6" (WxDxH) Material: powder coated steel Capacity: 20.4 Cu Ft Insulation: VIP (Vacuum Insulated Panel) 5x5x2" cryo box capacity: 400 |
| Shelf | Comes with unit: 3 (4 compartments), fully adjustable Dimensions: 23.8 x 26.7" (WxD) Max. capacity: 175 Lbs Material: 304 stainless steel |
| Door and gasket | Inner door: four, each with one sealing gasket External door: one, with four sealing gaskets, lock-able |
| Communication | Standard: RS-485, USB (stores 15 years of data for compliance purpose) Optional: 4-20mA transmitter |
| Access port | Two |
| Noise level | 50 dBA |
| Working environment | Temperature: 10°C to 32°C (humidity <57% Rh required at 32°C) Humidity: <80% Rh Altitude: <2000 m / 6561 Ft |
| Battery backup system | 48 hours (for controller display and alarms only) |
| Unit/shipping weight & dimensions | 660 Lbs / 730 Lbs 36 x 38.5 x 77" / 40 x 42 x 82" (WxDxH) |
| Safety | Compressor over-temp protection Ambient over-temp protection Compressor power surge delay protection Password protection Sensor failure protection Over-temperature and low-temperature protection Power failure protection Low battery, door open, condenser clogging, system failure alarms External door with lock Ground protection |
| Compliance | UL 61010-1 CSA C22.2 Energy Star |
| Warranty | 2-year full service, 5-year parts, 10-year compressor |
- Weight 385 Kg
- Dimensions 42 Inch x 38 Inch x 83 Inch
